Takumi SL-300 CNC Lathe, 2018 – New In Crate, 6 Month Part Warranty, Tailstock

Views: 1
Takumi SL-300 CNC Lathe, 2018 – New In Crate, 6 Month Part Warranty, Tailstock

$87,500.00



Great Opportunity to get a like new machine for a used machine price!



Takumi SL 300 with FANUC 0i-TF Control

Standard Specifications

X, Z -Axis Travel

10” x 27.55

Swing Over Bed

23.62”

Maximum Turning Diameter

17.71”

Maximum Turning Length

25.6”

Chuck Size

12”

Bore/Draw Tube Inner Diameter

4” / 3.58”

Spindle RPM / Type

3000 RPM / A2-8

Spindle Horsepower (30 min.)

25 HP

Spindle Motor Torque (Peak)

212 ft. lbs.

Turret Stations / Size

10 / 1”

Rapid Feed/Cutting Feed

787 IPM/393.7 IPM





Standard Machine Features

» Bar Feeder Interface

» Hardened and Ground Box Ways on All Axes

» Hand-Scraped Contact Areas

» 3,000 RPM 25 HP Heavy Duty Belt Drive Spindle / Type: A2-8

» Hydraulic Actuated 12” 3 Jaw Chuck with Hard and Soft Jaws

» Chuck and Tailstock Operation Foot Switches

» Fast 787 IPM Rapid Traverse Rate

» 393.7 IPM Cutting Feed Rate

» 10 Station Bi Directional Hydraulic 1” Tooling Turret

» 19 Piece Basic Tooling Kit

» Programmable Tailstock Body Mounted on Hardened Box Ways w/Hydraulic Quill

» High Intensity Work Light

» 3-Light Indicator Lamp

» Manual Pulse Generator (MPG)

» 55 Gallon Coolant Tank

» MT-5 Live Center

» Wash-Down Gun And Air gun

» Lift Up Chain Style Chip Conveyor w/cart

» Renishaw HPRA Removable Tool Setter

» 10.4” LCD FANUC 0i-TF Control

» Dynamic Graphic Display

» Rigid Tapping

» FANUC Manual Guide i

» Compact Flash Port

» USB Port

» Ethernet Port

» 6 Month Part Warranty

» Leveling Bolts and Pads

» Operator Manuals

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
