Takumi SL450 CNC Lathe, 2022 -Live Tooling C-Axis Never Used, New In Crate
$134,500.00
OVER 300k REPLACEMENT COST
6 Month Part Warranty
Heavy Duty Box Ways
Takumi SL450
(FANUC Oi-TF Plus Control)
Standard Specifications
X / Y Axis Travels 11.8” / 49.2”
Maximum Turning Diameter 22.4”
Maximum Turing Length 45.3”
Swing Over Bed 26.4”
Swing Over Cross Diameter 22.4”
Chuck Size 18”
Draw Tube Diameter 4.6”
Spindle Through Hole Diameter 5.15”
Spindle RPM 2000
Spindle Nose Type A2-11
Spindle Power (30 min / Continuous) 24.8 HP / 15.0 HP
Spindle Motor Torque (30 min / Continuous) 365 ft. lbs. / 288 ft. lbs.
Rapid Traverse (X/Y) 787 ipm
Turret Stations / Type 12 / BMT 65 DIN 1809
Maximum Boring Bar 1.57”
Live Tooling Power 7.4 HP
Live Tooling Speed Axial 6,000 RPM / Radial 5,000 RPM
Quill Travel / Diameter 4.92” / 3.54”
Tailstock Travel 46.3”
Accuracy / Repeatability 0.0006” / 0.0004”
Coolant Capacity 105 Gallons
Electrical Requirements 220 VAC / 35 KVA
Air Requirements 5 cfm 80-100 psi
Shipping Dimensions (W x D x H) 208.66” x 90.55” x100.78”
Operating Dimensions (W x D x H) 204.7” x106.3” x102.3”
Machine Weight 18,708 lbs
Shipping Weight 20,076 LBS
All specifications are assumed to be correct but must be confirmed by the purchasing entity.
